脉冲功率放大器
|
型号 |
关键技术指标 |
|
|
频率范围 |
输出功率W/dBm |
|
|
JCPA-07101000P |
698MHz-960MHz |
1000W/60dBm |
|
JCPA-07102000P |
2000W/63dBm |
|
|
JCPA-07103000P |
3000W/65dBm |
|
|
JCPA-07104000P |
4000W/66dBm |
|
|
JCPA-18221000P |
1805MHz-2170MHz |
1000W/60dBm |
|
JCPA-18222000P |
2000W/63dBm |
|
|
JCPA-18223000P |
3000W/65dBm |
|
|
JCPA-18224000P |
4000W/66dBm |
|
|
JCPA-23271000P |
2.3GHz-2.7GHz |
1000W/60dBm |
|
JCPA-23272000P |
2000W/63dBm |
|
|
JCPA-23273000P |
3000W/65dBm |
|
|
JCPA-23274000P |
4000W/66dBm |
|
|
JCPA-34381000P |
3.4GHz-3.8GHz |
1000W/60dBm |
|
JCPA-34382000P |
2000W/63dBm |
|
|
JCPA-34383000P |
3000W/65dBm |
|
|
JCPA-34384000P |
4000W/66dBm |
|
连续波功率放大器
|
型号 |
频段 |
功率 |
增益 |
尺寸 |
|
JCPA-300-400-1000 |
300-400MHz |
1000W |
58d8 |
480* 500* 450mm |
|
JCPA-400-500-1000 |
400-500MHz |
1000W |
58dB |
480* 500* 450mm |
|
JCPA-300-500-500 |
300-500MHz |
500W |
55dB |
480* 500* 360mm |
|
JCPA-728-960-1000 |
728-960MHz |
1000W |
58dB |
480* 500* 450mm |
|
JCPA-1805-2170-1000 |
1805-2170MHz |
1000W |
58dB |
480* 500* 450mm |
|
JCPA-2300-2700-1000 |
2300-2700MHz |
1000W |
58dB |
480* 500* 450mm |
|
JCPA-700-2700-500 |
700-2700MHz |
500W |
55dB |
480* 500* 450mm |
|
JCPA-3300-3800-1000 |
3300-3800MHz |
1000W |
58dB |
480* 500* 540mm |
|
JCPA-3800-4200-1000 |
3800-4200MHz |
1000W |
58dB |
480* 500* 540mm |
|
JCPA-4400-4900-500 |
4400-4900MHz |
500W |
58dB |
480* 500* 540mm |
电磁兼容功率放大器
|
型号 |
工作频率 |
功率 |
增益平坦度 |
通信方式 |
|
JCPA-0.009-400-100 |
9KHz-400MHz |
100W |
±3.5d8 |
GPIB、LAN |
|
JCPA-0.009-400-200 |
9KHz-400Hz |
200W |
±3.5dB |
GPIB、LAN |
|
JCPA-80-1000-250 |
80-1000MHz |
250W |
±4.0dB |
GPIB、LAN |
|
JCPA-1000-2500-200 |
1000-2500MHz |
200W |
±2.5dB |
GPIB、LAN |
|
JCPA-1000-3200-200 |
1000-3200MHz |
200W |
±2.5dB |
GPIB、LAN |
|
JCPA-1000-6000-100 |
1-6GHz |
100W |
±4.0dB |
GPIB、LAN |
|
JCPA-1000-6000-200 |
1-6GHz |
200W |
±4.0d8 |
GPIB、LAN |
|
JCPA-6000-18000-200 |
6-18GHz |
200W |
±2.5dB |
GPIB、LAN |
|
JCPA-18000-26500-50 |
18-26.5GHz |
50W |
±2.5dB |
GPIB、LAN |
|
JCPA-26500-40000-40 |
26.5-40GHz |
40W |
±2.5d8 |
GPIB、LAN |
